雙11福利 | 2024年無損檢測ISO標準全集，8種方法101個標準，高清電子版免費獲取！
雙11福利 | 2024年無損檢測ISO標準全集，8種方法101個標準，高清電子版免費獲取！
來源：領翼國際無損檢測學校
發布日期：2024-11-12 10:02
ISO標準
如何獲取高清電子版
2024年無損檢測ISO標準全集
高清電子版，獲取方式見文后
ISO 國際組織共有340個技術委員會，其中第135個，就是無損檢測。
截至今日，該技術委員會共發布101個NDT相關的ISO標準，詳情如下：
|
ISO/TC/135 分技術委員會 |
發布標準數量 |
|
ISO/TC/135/SC2 表面檢測方法 |
14 |
|
ISO/TC/135/SC3 超聲檢測 |
22 |
|
ISO/TC/135/SC4 渦流檢測 |
7 |
|
ISO/TC/135/SC5 射線檢測 |
28 |
|
ISO/TC/135/SC6 泄漏檢測 |
4 |
|
ISO/TC/135/SC7 人員認證 |
7 |
|
ISO/TC/135/SC8 紅外熱像檢測 |
5 |
|
ISO/TC/135/SC9 聲發射檢測 |
13 |
標準詳細目錄如下：
ISO
////
ISO/TC 135/SC 2 Surface methods
表面檢測共有14個相關標準
ONE
|
1 |
ISO 3057:1998 Non-destructive testing — Metallographic replica techniques of surface examination |
|
2 |
ISO 3058:1998 Non-destructive testing — Aids to visual inspection — Selection of low-power magnifiers |
|
3 |
ISO 3059:2012 Non-destructive testing — Penetrant testing and magnetic particle testing — Viewing conditions |
|
4 |
ISO 3452-1:2021 Non-destructive testing — Penetrant testing —Part 1: General principles |
|
5 |
ISO 3452-2:2021 Non-destructive testing — Penetrant testing — Part 2: Testing of penetrant materials |
|
6 |
ISO 3452-3:2013 Non-destructive testing — Penetrant testing — Part 3: Reference test blocks |
|
7 |
ISO 3452-4:1998 Non-destructive testing — Penetrant testing — Part 4: Equipment |
|
8 |
ISO 3452-5:2008 Non-destructive testing — Penetrant testing — Part 5: Penetrant testing at temperatures higher than 50 degrees C |
|
9 |
ISO 3452-6:2008 Non-destructive testing — Penetrant testing — Part 6: Penetrant testing at temperatures lower than 10 degrees C |
|
10 |
ISO 9934-1:2016 Non-destructive testing — Magnetic particle testing — Part 1: General principles |
|
11 |
ISO 9934-2:2015 Non-destructive testing — Magnetic particle testing — Part 2: Detection media |
|
12 |
ISO 9934-3:2015 Non-destructive testing — Magnetic particle testing — Part 3: Equipment |
|
13 |
ISO 12706:2009 Non-destructive testing — Penetrant testing — Vocabulary |
|
14 |
ISO 12707:2016 Non-destructive testing — Magnetic particle testing — Vocabulary |
ISO
////
ISO/TC 135/SC 3 Ultrasonic testing
超聲檢測共有22個標準
TWO
|
1 |
ISO 2400:2012
Non-destructive testing — Ultrasonic testing — Specification for calibration block No. 1 |
|
2 |
ISO 4773:2023
Non-destructive testing — Ultrasonic guided-wave testing using the phased-array technique |
|
3 |
ISO 5577:2017
Non-destructive testing — Ultrasonic testing — Vocabulary |
|
4 |
ISO 7963:2022
Non-destructive testing — Ultrasonic testing — Specification for calibration block No. 2 |
|
5 |
ISO 16809:2017
Non-destructive testing — Ultrasonic thickness measurement |
|
6 |
ISO 16810:2024
Non-destructive testing — Ultrasonic testing — General principles |
|
7 |
ISO 16811:2012
Non-destructive testing — Ultrasonic testing — Sensitivity and range setting |
|
8 |
ISO 16823:2012
Non-destructive testing — Ultrasonic testing — Transmission technique |
|
9 |
ISO 16826:2012
Non-destructive testing — Ultrasonic testing — Examination for discontinuities perpendicular to the surface |
|
10 |
ISO 16827:2012
Non-destructive testing — Ultrasonic testing — Characterization and sizing of discontinuities |
|
11 |
ISO 16828:2012
Non-destructive testing — Ultrasonic testing — Time-of-flight diffraction technique as a method for detection and sizing of discontinuities |
|
12 |
ISO/TS 16829:2017
Non-destructive testing — Automated ultrasonic testing — Selection and application of systems |
|
13 |
ISO 16831:2012
Non-destructive testing — Ultrasonic testing — Characterization and verification of ultrasonic thickness measuring equipment |
|
14 |
ISO 16946:2024 Non-destructive testing — Ultrasonic testing — Specification for a step wedge standard block |
|
15 |
ISO 18563-1:2022 Non-destructive testing — Characterization and verification of ultrasonic phased array equipment — Part 1: Instruments |
|
16 |
ISO 18563-2:2024
Non-destructive testing — Characterization and verification of ultrasonic phased array equipment — Part 2: Array probes |
|
17 |
ISO 18563-3:2024
Non-destructive testing — Characterization and verification of ultrasonic phased array equipment — Part 3: Complete systems |
|
18 |
ISO 22232-1:2020
Non-destructive testing — Characterization and verification of ultrasonic test equipment — Part 1: Instruments |
|
19 |
ISO 22232-2:2020
Non-destructive testing — Characterization and verification of ultrasonic test equipment — Part 2: Probes |
|
20 |
ISO 22232-3:2020 Non-destructive testing — Characterization and verification of ultrasonic test equipment — Part 3: Combined equipment |
|
21 |
ISO 23243:2020
Non-destructive testing — Ultrasonic testing with arrays — Vocabulary |
|
22 |
ISO 24647:2023
Non-destructive testing — Robotic ultrasonic test systems — General requirements |
ISO
////
ISO/TC 135/SC 4 Eddy current testing
渦流檢測共有7個相關標準
THREE
|
1 |
ISO 12718:2019
Non-destructive testing — Eddy current testing — Vocabulary |
|
2 |
ISO 15548-1:2013
Non-destructive testing — Equipment for eddy current examination — Part 1: Instrument characteristics and verificatio |
|
3 |
ISO 15548-2:2013
Non-destructive testing — Equipment for eddy current examination — Part 2: Probe characteristics and verification |
|
4 |
ISO 15548-3:2008
Non-destructive testing — Equipment for eddy current examination — Part 3: System characteristics and verification |
|
5 |
ISO 15549:2019
Non-destructive testing — Eddy current testing — General principles |
|
6 |
ISO 20339:2017
Non-destructive testing — Equipment for eddy current examination — Array probe characteristics and verification |
|
7 |
ISO 20669:2017
Non-destructive testing — Pulsed eddy current testing of ferromagnetic metallic components |
ISO
////
ISO/TC 135/SC 5 Radiographic testing
射線檢測共有28個相關標準
FOUR
|
1 |
ISO 5576:1997
Non-destructive testing — Industrial X-ray and gamma-ray radiology — Vocabulary |
|
2 |
ISO 5579:2013 Non-destructive testing — Radiographic testing of metallic materials using film and X- or gamma rays — Basic rules |
|
3 |
ISO 5580:2023
Non-destructive testing — Industrial radiographic illuminators — Minimum requirements |
|
4 |
ISO 11699-1:2008
Non-destructive testing — Industrial radiographic film — Part 1: Classification of film systems for industrial radiography |
|
5 |
ISO 11699-2:2018
Non-destructive testing — Industrial radiographic films — Part 2: Control of film processing by means of reference values |
|
6 |
ISO 12721:2000
Non-destructive testing — Thermal neutron radiographic testing — Determination of beam L/D ratio |
|
7 |
ISO 14096-1:2005
Non-destructive testing — Qualification of radiographic film digitisation systems — Part 1: Definitions, quantitative measurements of image quality parameters, standard reference film and qualitative control |
|
8 |
ISO 14096-2:2005
Non-destructive testing — Qualification of radiographic film digitisation systems — Part 2: Minimum requirements |
|
9 |
ISO 15708-1:2024
Non-destructive testing — Radiation methods for computed tomography — Part 1: Vocabulary |
|
10 |
ISO 15708-2:2017
Non-destructive testing — Radiation methods for computed tomography — Part 2: Principles, equipment and samples |
|
11 |
ISO 15708-3:2017 Non-destructive testing — Radiation methods for computed tomography — Part 3: Operation and interpretation |
|
12 |
ISO 15708-4:2017 Non-destructive testing — Radiation methods for computed tomography — Part 4: Qualification |
|
13 |
ISO 16371-1:2011 Non-destructive testing — Industrial computed radiography with storage phosphor imaging plates — Part 1: Classification of systems |
|
14 |
ISO 16371-2:2017 Non-destructive testing — Industrial computed radiography with storage phosphor imaging plates — Part 2: General principles for testing of metallic materials using X-rays and gamma rays |
|
15 |
ISO 16526-1:2011 Non-destructive testing — Measurement and evaluation of the X-ray tube voltage — Part 1: Voltage divider method |
|
16 |
ISO 16526-2:2011 Non-destructive testing — Measurement and evaluation of the X-ray tube voltage — Part 2: Constancy check by the thick filter method |
|
17 |
ISO 16526-3:2011 Non-destructive testing — Measurement and evaluation of the X-ray tube voltage — Part 3: Spectrometric method |
|
18 |
ISO 19232-1:2013 Non-destructive testing — Image quality of radiographs — Part 1: Determination of the image quality value using wire-type image quality indicators |
|
19 |
ISO 19232-2:2013
Non-destructive testing — Image quality of radiographs — Part 2: Determination of the image quality value using step/hole-type image quality indicators |
|
20 |
ISO 19232-3:2013 Non-destructive testing — Image quality of radiographs — Part 3: Image quality classes |
|
21 |
ISO 19232-4:2013 Non-destructive testing — Image quality of radiographs — Part 4: Experimental evaluation of image quality values and image quality tables |
|
22 |
ISO 19232-5:2018 Non-destructive testing — Image quality of radiographs — Part 5: Determination of the image unsharpness and basic spatial resolution value using duplex wire-type image quality indicators |
|
23 |
ISO 20769-1:2018 Non-destructive testing — Radiographic inspection of corrosion and deposits in pipes by X- and gamma rays — Part 1: Tangential radiographic inspection |
|
24 |
ISO 20769-2:2018 Non-destructive testing — Radiographic inspection of corrosion and deposits in pipes by X- and gamma rays — Part 2: Double wall radiographic inspection |
|
25 |
ISO 21432:2019
Non-destructive testing — Standard test method for determining residual stresses by neutron diffraction |
|
26 |
ISO 23159:2020
Non-destructive testing — Gamma ray scanning method on process columns |
|
27 |
ISO 32543-1:2024 Non-destructive testing — Characteristics of focal spots in industrial X-ray systems — Part 1: Pinhole camera radiographic method |
|
28 |
ISO 32679:2024
Non-destructive testing — Radiographic testing — Determination of the size of industrial radiographic gamma sources |
ISO
////
ISO/TC 135/SC 6 Leak testing
泄漏檢測共有4個標準
FIVE
|
1 |
ISO 3530:1979 Vacuum technology — Mass-spectrometer-type leak-detector calibration |
|
2 |
ISO 20484:2017
Non-destructive testing — Leak testing — Vocabulary |
|
3 |
ISO 20485:2017
Non-destructive testing — Leak testing — Tracer gas method |
|
4 |
ISO 20486:2017
Non-destructive testing — Leak testing — Calibration of reference leaks for gases |
ISO
////
ISO/TC 135/SC 7 Personnel qualification
人員認證有7個相關標準
SIX
|
1 |
ISO 12718:2019
Non-destructive testing — Eddy current testing — Vocabulary |
|
2 |
ISO 15548-1:2013
Non-destructive testing — Equipment for eddy current examination — Part 1: Instrument characteristics and verificatio |
|
3 |
ISO 15548-2:2013
Non-destructive testing — Equipment for eddy current examination — Part 2: Probe characteristics and verification |
|
4 |
ISO 15548-3:2008
Non-destructive testing — Equipment for eddy current examination — Part 3: System characteristics and verification |
|
5 |
ISO 15549:2019
Non-destructive testing — Eddy current testing — General principles |
|
6 |
ISO 20339:2017
Non-destructive testing — Equipment for eddy current examination — Array probe characteristics and verification |
|
7 |
ISO 20669:2017
Non-destructive testing — Pulsed eddy current testing of ferromagnetic metallic components |
ISO
////
ISO/TC 135/SC 8 Thermographic testing
紅外熱像檢測有4個標準
SEVEN
|
1 |
ISO 10878:2013 Non-destructive testing — Infrared thermography — Vocabulary |
|
2 |
ISO 10880:2017
Non-destructive testing — Infrared thermographic testing — General principles |
|
3 |
ISO 18251-1:2017
Non-destructive testing — Infrared thermography — Part 1: Characteristics of system and equipment |
|
4 |
ISO 18251-2:2023
Non-destructive testing — Infrared thermography — Part 2: Test method for integrated performance of system and equipment |
|
5 |
ISO 22290:2020
Non-destructive testing — Infrared thermographic testing — General principles for thermoelastic stress measuring method |
ISO
////
ISO/TC 135/SC 9 Acoustic emission testing
聲發射檢測目前有13個標準
EIGHT
|
1 |
ISO 12713:1998 Non-destructive testing — Acoustic emission inspection — Primary calibration of transducers |
|
2 |
ISO 12714:1999 Non-destructive testing — Acoustic emission inspection — Secondary calibration of acoustic emission sensors |
|
3 |
ISO 12716:2001 Non-destructive testing — Acoustic emission inspection — Vocabulary |
|
4 |
ISO/TR 13115:2011 Non-destructive testing — Methods for absolute calibration of acoustic emission transducers by the reciprocity technique |
|
5 |
ISO 16836:2019 Non-destructive testing — Acoustic emission testing — Measurement method for acoustic emission signals in concrete |
|
6 |
ISO 16837:2019 Non-destructive testing — Acoustic emission testing — Test method for damage qualification of reinforced concrete beams |
|
7 |
ISO 16838:2019 Non-destructive testing — Acoustic emission testing — Test method for classification of active cracks in concrete structures |
|
8 |
ISO 18081:2024 Non-destructive testing — Acoustic emission testing (AT) — Leak detection by means of acoustic emission |
|
9 |
ISO 18249:2015 Non-destructive testing — Acoustic emission testing — Specific methodology and general evaluation criteria for testing of fibre-reinforced polymers |
|
10 |
ISO 19835:2018 Non-destructive testing — Acoustic emission testing — Steel structures of overhead travelling cranes and portal bridge cranes |
|
11 |
ISO 24367:2023 Non-destructive testing — Acoustic emission testing — Metallic pressure equipment |
|
12 |
ISO 24489:2024 Non-destructive testing — Acoustic emission testing — Detection of corrosion at atmospheric and low-pressure metallic storage tank floors |
|
13 |
ISO 24543:2022 Non-destructive testing — Acoustic emission testing — Verification of the receiving sensitivity spectra of piezoelectric acoustic emission sensors |
